Portable Line Boring Machine BD-60

Portable-Line-Boring-Welding-Machine-BD-60 (1)

Portable Line Boring & Welding Machine are utilized for delivering smooth and exact openings in a workpiece by expanding existing gaps with a drag, this may bear a solitary cutting tip of steel, established carbide, or precious stone or might be a little granulating wheel.

Know the features of line boring machines!
Are you looking to buy a boring machine to me your requirements you project or job requirements? Look down to the basic features and benefits you will get by getting one!
The line boring machine helps to cut the inside of the bore to enlarge its diameter. The boring machines are developed so that a bore could be made in the shortest time, by producing the highest tolerances and possible surface finish with it. A boring line machine actually helps to bore in the heavy construction equipment’s such as in the end loaders and cranes as it is very economical equipment. A bore machine is very powerful, flexible and very easy to use which is available with a drive.
How do they work?
Line boring machines utilized in apparatus influencing shops to have one vertical shaft and a work-holding table that can be moved evenly in two ways opposite to each other so gaps can be precisely dispersed. On a few machines, the dividing blunder is under 0.003 percent. In large-scale manufacturing plants, extraordinary exhausting machines with various shafts are normal.

Auto Boring & Welding Systems has a quick and easy setup
Quick and straightforward setup using splendid cast-squeeze set-up cones and round bearing mounts.
• Protected roundabout bearing mounting system grants expedient setup, with up to 4° of bearing misalignment.
Regular set-up time for an expert manager is 25-30 minutes or less.

Technical information and evaluation

Bar shaft diameter: 60 mm.

In-hole machining diameter (boring): From 62mm to 700mm.

In-hole machining diameter (welding): From 65mm to 700mm.

Bar shaft turn motor:

AC Servo Motor – Voltage:230VAC

Min: 0.20 Rpm. (rev/min.)  –  Max: 225 Rpm. (rev/min.)

Bar shaft Forward and reverse motion motor:

DC Servo Motor – Power:90Watts, Voltage:24VDC

Speed Range min: 0.05mm/min   –   max: 95mm/min

Stroke : 250mm.

● Wide speed range, flat torque
● Excellent speed stability
● Compact and high power
● High efficiency and energy-saving

Working voltage:

230VAC  50/60 hz – 10 Amp.

Control circuit devices and switching elements :

● Start / Stop  switch
● Emergency button
● Toggle switches(Right left rotation switch/stepping)
● Emergency button
● Speed/cyclic control knob
 Move back and forth stepping switch
● Fast motion button
● Reset button
 Control screen

Some features that make LINEBORTECH portable boring machine different

More powerful and trouble-free with the engine-coupled transmission.
The gears are hardened with 55 HRC and are made more durable.
High standard modular design for ease of installation and transport.
Easy installation due to the structure consisting of light and durable materials.
The electronic panel allows you to control the sensitivity and power at the same time.
We produce reliable products with 600 hours working guarantee.

The portable line boring machine should comprise of quality workmanship along with site tolerances and they are really easy to set up and install. These machines are of robust design and construction.

BD-60 Standard Equipment List

LINEBORTECH Portable Line Boring & Welding Machine delivers your projects on time and makes quality much easier; With our professional technical machines, you can make your sensitive operations much easier. You will confirm the quality of all the equipment we use.

How can we help you?

Portable line boring welding machine are mounted on the workpiece with a three-point carrier material. For example; If the connection holes of an excavator bucket are to be machined. They are mounted on the workpiece of the portable line boring welding machine with various connection equipment so as not to cause axis misalignment.
